Overdrive / Distortion
4-in-1 pedal that offers two classic distortion / fuzz circuits and two new combinations of clipping circuit and tone control
Features the ability to combine the best and most characteristic features of different overdrive and boost pedals
Switchable between True Bypass or completely silent Buffered Bypass via footswitch
Tone control switch for selecting different tone control circuits
Drive switch for selecting hard or soft clipping
True Bypass and Buffered Bypass
Controls: Tone, Drive and Level
Switch for Tone SD / RT, Drive SD / RT
Bypass foot switch
Status LED
Line input: 6.3 mm jack
Line output: 6.3 mm jack plug
Power supply connection: Barrel plug 5.5 x 2.1 mm, centre negative
Power supply via 9 - 18 V DC power supply unit
Power consumption: 27 mA
Aluminium housing
Dimensions (L x W x H): 127 x 67 x 70 mm
Weight: 290 g
Made in USA
